NOMINAL SIZE (I.D.) |
STANDARD
LENGTH
( ft. ) |
PRESSURE at 20¢XC |
TOLERABLE
BENDING
RADIUS
(m/m ) |
|
m / m |
inch |
WORKING
( kg/cm2 ) |
BURSTING
( kg/cm2 ) |
|
25 |
1 |
200 |
4.0 |
15.0 |
45 |
|
32 |
1-1/4 |
200 |
4.0 |
15.0 |
50 |
|
38 |
1-1/2 |
200 |
3.5 |
13.0 |
55 |
|
50 |
2 |
150 |
3.5 |
13.0 |
110 |
|
65 |
2-1/2 |
150 |
2.5 |
12.0 |
180 |
|
75 |
3 |
100 |
2.5 |
12.0 |
220 |
|
88 |
3-1/2 |
100 |
2.5 |
11.0 |
230 |
|
100 |
4 |
100 |
2.5 |
10.0 |
240 |
|
114 |
4-1/2 |
100 |
2.5 |
10.0 |
320 |
|
125 |
5 |
100 |
2.5 |
10.0 |
400 |
|
150 |
6 |
100 |
2.0 |
8.0 |
450 |
|
|
|
|
|
|
|
|
 |
|
|
¡E |
Smooth
inner wall providing a good flow of fluids. |
|
¡E |
Material's movement inside the hose can be seen. |
|
¡E |
High
flexibility due to corrugated outer surface. |
|
¡E |
Good
resistance against abrasion and deformation. |
|
|
|
|
|
 |
|
|
¡E |
For
discharging/supplying water used in agriculture, fish ponds,
industry, construction, civil engineering and ships etc. |
|
¡E |
For
transporting of pulverized body or chemicals. |
|
¡E |
For
conveyance of foods and beverages. |
|
¡E |
For
other suction usages in factories. |
|
| ¡@ ¡@ |
|
¡@ |
 |
