Type (A) |
|
NOMINAL SIZE (inch) |
ID X OD
(m / m) |
PRESSURE at 20˘XC |
STANDARD
LENGTH
( M ) |
|
WORKING
( kg/cm2 ) |
BURSTING
( kg/cm2 ) |
|
3 / 16 |
5 X 10 |
15 |
60 |
100 |
|
1 / 4 |
6 X 11 |
15 |
60 |
100 |
|
5 / 16 |
8 X 13.5 |
12 |
50 |
100 |
|
3 / 8 |
9 X 15 |
12 |
50 |
100 |
|
1 / 2 |
12 X 18 |
10 |
40 |
100 |
|
5 / 8 |
16 X 22 |
10 |
40 |
50 |
|
3 / 4 |
19 X 26 |
8 |
35 |
50 |
|
1 |
25 X 33 |
7 |
30 |
50 |
|
1-1 / 4 |
32 X 41 |
5 |
20 |
50 |
|
1-1 / 2 |
38 X 48 |
5 |
20 |
50 |
|
2 |
50 X 62 |
4 |
15 |
50 |
|
|
|
Type (B) |
|
NOMINAL SIZE (inch) |
ID X OD
(m / m) |
PRESSURE
at 20˘XC |
STANDARD
LENGTH
( M ) |
|
WORKING
( kg/cm2
) |
BURSTING
( kg/cm2
) |
|
3 / 16 |
5 X 9 |
10 |
40 |
100 |
|
1 / 4 |
6 X 10 |
10 |
40 |
100 |
|
5 / 16 |
8 X 12 |
9 |
35 |
100 |
|
3 / 8 |
9 X 14 |
9 |
35 |
100 |
|
1 / 2 |
12 X 17 |
7 |
30 |
100 |
|
5 / 8 |
16 X 21 |
6 |
25 |
50 |
|
3 / 4 |
19 X 25 |
5 |
20 |
50 |
|
1 |
25 X 32 |
5 |
20 |
50 |
|
1-1 / 4 |
32 X 40 |
4 |
15 |
50 |
|
1-1 / 2 |
38 X 47 |
4 |
15 |
50 |
|
2 |
50 X 60 |
2.5 |
10 |
50 |
|
|
|
|
|
|
 |
|
|
ĦE |
Water supply and
drainage on machines, and equipments in factories. |
|
ĦE |
For piping the air
pressure equipment. |
|
ĦE |
For conveying all
types of powder and granular substance. |
|
ĦE |
For shower hoses, gas
hoses, fire extinguisher hoses and other special usages. |
|
|
|
|
|
 |
|
|
ĦE |
Light weight and
flexible. |
|
ĦE |
Easy coupling. |
|
ĦE |
Excellent pressure
resistance. Low, medium and high pressure are available for multipurpose. |
|
ĦE |
Corrosion free,
little expansion or contraction. |
|
